LevelOne VDS-1201 - Page 2

2
DSL: “Green On” indicates VDSL2 is in connection.
“Flashing” indicates VDSL2 is in line handshaking.
M/S: “Green On” indicates device is set as Slave (VTU-R) mode.
“OFF” indicates device is set as Master (VTU-C) mode.
*refer to DIP Switch Pin 1
Dip Switches Settings
ON
1 2 3 4
Pin 1
Pin 2
Pin 3
Pin 4
VTU-C/R
Profile
Profile
SNR
OFF
VTU-CO
30a
Annex A
9dB
ON
VTU-CPE
17a
Annex B
(ISDN 997)
6dB
ON
1 2 3 4
Pin 1: VTU-C/R Switch
VTU-C: V102M-PD will act as at the Central Office (CO) side.
VTU-R: V102M-PD will act as at the Customer Premise Equipment (CPE) or Remote side.
ON
1 2 3 4
Pin 2: Mode for VDSL2 Connection Profile
30a: for VDSL2 30a profile
17a: for VDSL2 17a profile.
ON
1 2 3 4
Pin 3: Mode for VDSL2 Annex.A/B
Annex.A: for VDSL2 Annex.A 30a/17a.
Annex.B: for VDSL2 Annex.B 30a/17a.
