LevelOne VDS-1201 - Page 3

3
ON
1 2 3 4
Pin 4: Signal to Noise Ratio (SNR) Margin
9dB: Higher SNR margin (9dB) will result in less error with more stable VDSL2 link.
6dB: Original and Normal channel noise protection with 6 dB SNR.
VDS-1201/1202 Data Rates & Distances
Performance in AWG 24 Line at 6dB with full rate
Down Stream
Data Rate (Mbps)
Up Stream
Data Rate (Mbps)
Distance
(feet)
100
100
1000
90
70
1250
80
60
1500
70
45
1750
60
38
2000
48
28
2500
39
18
3000
35
10
3500
28
3
4000
VDS-1203 Data Rates & Distances
Performance in 5C2V Cable at 6dB with full rate
Down Stream
Data Rate (Mbps)
Up Stream
Data Rate (Mbps)
Distance
(feet)
100
100
1500
96
51
1750
88
48
2000
81
45
2500
77
37
3000
70
32
3500
63
27
4500
