Page 7
REMOVING THE TOUCHSCREEN
After installation, if it is necessary to remove the touchscreen from the
wall:
a) Remove the screws that secure the touchscreen to the mounting
bracket.
b) Push the touchscreen upward and then lift it away from the wall.
Figure 6
c. Secure the touchscreen to the mounting bracket flanges using
the provided screws.
