Dept 40 PANEL ASSEMBLY
# HINGE/PAN: 3 HINGE 2: 19 9/16
Item UM Qty BATCH 648292 - 2
2 EACH 1 LEVOLOR SHUTTER
3 1/2” ELLIPTICAL LOUVER Color: VANILLA
Width: 35 1/4 Height: 46 5/8 Mount: INSIDE Shutter Style: STANDARD Panel Configuration: LR Frame Selection: Z FRAME # of Frame
Sides: 4 Frame Sides: 4 SIDES - Left-Right-Top-Bottom Sill - 04-LRTBS Total Number of Panels: P2 Panel Set #1: 2 PANELS - Left-Right-LR
Tilt Option: CLEAR TILT SOLID Divider Rail: 1 DIVIDER RAIL Divider Rail #1 Type: REGULAR Divider Rail #1 Location: 24
Hinges: PAINTED FINISH Panel Lock: PANEL LOCK Room Location: NOOK Rail and Cap Selection: B2 B1
GETTING STARTEDCONTENTS
2 3
Shutters Installation Manual © 2021 LEVOLOR, Inc. Shutters Installation Manual
Thank you for purchasing LEVOLOR
®
Shutters. With proper installation, operation, and care, your new shutters will
provide years of beauty and performance. Please thoroughly review this instruction booklet before beginning installation.
Please visit LEVOLOR.com/Shutters to view installation videos and Spanish translation.
INSTALLATION OVERVIEW
All frame styles and configurations follow the same basic installation process:
1. Review the packing slip and product labels to identify your frame style and mounting application
2. Organize tools and components
3. Assemble the frame
4. Fasten the frame in two points
5. Hang shutter panel(s)
6. Confirm the product is square / level
7. Fasten the remaining screws into the frame
8. Finishing touches such as panel lock adjustment, screw caps and caulking
STEP 1: REVIEW THE PACKING SLIP AND PRODUCT LABELS
Check the room location on the packaging slip, as it should match what was entered during time of order. Additionally,
check for the following items, and make note of these selections, as it will affect further steps:
Record the Mount, Frame Style and number of T-Posts (if applicable), as it will be necessary for later steps in this guide.
Packing Slip Example:
Getting Started ....................................................................................................................................................3–4
Installation Overview ........................................................................................................................................... 3
Tools and Fasteners You May Need .................................................................................................................... 4
Organize Parts and Components ........................................................................................................................ 4
Standard Shutter Installation ...........................................................................................................................5–9
Assemble the Frame ............................................................................................................................................ 5
Partially Fasten frame .......................................................................................................................................... 6
Hang Panels ......................................................................................................................................................... 7
Square & Level Panels ......................................................................................................................................... 7
Fully Fasten Frame ............................................................................................................................................... 7
Finishing Touches ........................................................................................................................................... 8–9
Additional Installation Instructions (if needed) ........................................................................................... 9–14
T-Post Installation .......................................................................................................................................... 9-10
Motorized Shutter Set Up .................................................................................................................................. 11
French Door Shutter Installation .......................................................................................................................12
By-Pass Installation ............................................................................................................................................13
Troubleshooting ................................................................................................................................................15–17
Cleaning & Care ......................................................................................................................................................18
Additional Information and Support....................................................................................................................18
Warranty .............................................................................................................................................................18
Customer Service Support ................................................................................................................................18
This example shows the following:
• Width: 35
1
⁄4 in
• Height: 46
5
⁄8 in
• Mount: Inside
• Frame: Z Frame
• # of Frames: 4 Sides
• Room Location: Nook
Panel Label
Top Frame Label
SAM001 SM. TEST 648292-2 1 of 1
P.O SAMPLE: Rm: - 6592
W: 35 1/4 H: 46 5/8 (01) Panel 1
Style : STANDARD
WO-LN Pnis Col Slat
648292-2 P2L VANILLA 4 1/2”
SAM001 SM. TEST 648292-2 1 of 1
P.O SAMPLE: Rm: - 32767
Z Frame - Top Frame
WO-LN Pnis Col Slat Size Cut
648292-2 P2 VANILLA 4 1/2 13.1250 45-45
PUNCH FRAME
Order
number:
648292
Number of
Shutters
Line Number:
2
PRODUCT LABEL
• Each frame will be identified with a removable label.
• Match the
line number
of the frame to the
line number
of the panel.
• Do not remove labels until product is installed.
To Next Page
