Lewmar CPX Vertical Winlass ref 66300104 Iss. 5 | 11
4.4 Control switch installation
NOTE: Wireless remote also
available.
NOTE: Wireless remote can only
be used if a contactor is fitted.
See wireless remote instructions
for wiring details.
Follow the mounting instructions supplied with the switch.
NOTE: In a multi station installation all switches must be wired in a parallel circuit.
MODEL CIRCUIT BREAKER CONTACTOR CONTROL BOX
CPX1
90 A (68000349) 68000318 68000129
CPX2
90 A (68000349) 68000318 68000129
CPX2
50 A (68000348) 68000319 68000130
CPX3
110 A (68000350) 68000318 68000129
CPX3
90 A (68000349) 68000319 68000130
CPX4
150 A (68000351) 68000320 18000200
CPX4
110 A (68000350) 68000321 18000237
CPX5
150 A (68000359) 68000318 68000128
CPX5
110 A (68000350) 68000318 68000130
MODEL VOLTAGE CABLE SIZING FOR LENGTH OF CABLE RUN
V 0  7 M 0  23 FT 7  15 M 23  50 FT 15  22 M 50  73 FT
CPX1
12 10 mm2 6 AWG 16 mm2 6 AWG 25 mm2 4 AWG
CPX2
12 10 mm2 6 AWG 16 mm2 6 AWG 25 mm2 4 AWG
CPX2
24 6 mm2 10 AWG 6 mm2 8 AWG 10 mm2 8 AWG
CPX3
12 16 mm2 6 AWG 25 mm2 2 AWG 35 mm2 0 AWG
CPX3
24 10 mm2 8 AWG 16 mm2 6 AWG 25 mm2 4 AWG
CPX4
12 25 mm2 3 AWG 35 mm2 0 AWG 50 mm2 0 AWG
CPX4
24 10 mm2 8 AWG 16 mm2 4 AWG 25 mm2 2 AWG
CPX5
12 25 mm2 3 AWG 35 mm2 0 AWG 50 mm2 0 AWG
CPX5
24 10 mm2 8 AWG 16 mm2 4 AWG 25 mm2 2 AWG
WIRELESS REMOTE 3 BUTTON WINDLASS ONLY WIRELESS REMOTE 5 BUTTON WINDLASS AND THRUSTER
68000967 68000968
