Lexicon CP-1 User Manual

Page 53
CP-1 Digital Audio Environment Processor
7
Specifications
Patents are pending on the CP-1
Unprocessed channels: 10 Hz - 100 kHz, +1, -3dB*
Processed channels: 10 Hz - 16 kHz, +1, -3dB*
*Ref. 1 kHz
Frequency Response:
Front: Less than .05%, 1 kHz, max level
Sides: Less than .05%, 1 kHz, max level
Center: Less than .05%, 1 kHz, max level
Rears: Less than .05%, 1 kHz, max level
Subwoofer: Less than .05%, 10 - 100 Hz, max level
THD:
300 mVRMS
Minimum Input Level:
Maximum Output Level: 3.5 VRMS
Input Impedance:
50 k ohms
Output Impedance:
500 ohms
Signal to Noise Ratio:
85dB min, A-weighted, Ref. 1 kHz max level
120V/60 Hz
100V/50-60 Hz
220V/50 Hz
240V/50 Hz
17"W x 12.5"D x 2.5"H
11 lbs.
Rack-mount adapter, Lexicon Part# 021-06639
Voltage:
Dimensions:
Weight:
Optional Equipment:
Specifications subject to change without notice.
