A-3
Appendix
MC-12/MC-12 Balanced
Video Inputs and Outputs
Video Inputs 5 composite (RCA),
8 S-video, and
4 component video
(3 RCA, 1 BNC)
Video Outputs 4 composite (RCA,
2 monitor and 2 record),
4 S-video (2 monitor and
2 record), and
1 component (BNC)
Performance (Composite & S-video)
NTSC M, PAL, and SECAM compatible
Switching Active
Output Level 1.0V peak-to-peak
Impedance 75Ω
Input Return Loss >40dB
Differential Gain <0.5%
Differential Phase <0.5°
Bandwidth >25MHz
K Factor <0.3%
Gain ±0.15dB
Signal/Noise Ratio >70dB
Frequency Response 10Hz to 10MHz + 0.1/
-0.3dB
Performance (Component Video)
3-channel (Y, Pr, Pb), format-independent
Switching Passive
Impedance 75Ω
Bandwidth >300MHz
Insertion Loss <3dB
Other
Microphone Inputs 4 3.5mm miniature phone
jacks
Input sensitivity: 10mVrms (400mV
maximum input level)
Input Impedance: 20kΩ (accepts balanced or
unbalanced input
signals)
Trigger Outputs 1 power on/off trigger,
2 programmable triggers;
+12 VDC, 0.5 amps each;
detachable screw
terminals
RS-232 Serial 2 9-pin D-sub connectors
Input/Output for system control and
software upgrades
Power Requirements 90-250 VAC, 50-60Hz,
90W (universal line input),
detachable power cord
Dimensions
MC-12: 17.3"w x 5.2"h x 14.85"d
(440 x 132 x 377mm)
MC-12 Balanced: 17.3"w x 6.63"h x 14.85"d
(440 x 169 x 377mm)
Weight
MC-12: 36lbs (16.4kg)
MC-12 Balanced: 45lbs (20.5kg)
Rack Mounting Optional brackets are
available for mounting
either unit in a standard
19" equipment rack
Other (continued)
Environment
Operating Temp: 0° to 35°C (32° to 95°F)
Storage Temp: -30° to 75°C (-22° to
167°F)
Relative Humidity: 95% maximum without
condensation
Remote Control Hand-held, battery-
powered infrared remote
control unit
Batteries: Two AA
