Basic Operation
Lexicon
MC-12 BALANCED FRONT PANEL
1
2 4 5
6
7
8
9
10
11
12
3
The MC-12 Balanced front panel is pictured below. The MC-12 front panel is pictured on page 2-6. Both are
identical, except the MC-12 Balanced has a larger chassis.
Red LED
Blue LED
Amber LED
IR RECEIVER
