The ZONE 2 AUDIO OUTPUTS provide analog audio output in
Zone 2. Two stereo outputs (one fixed, one variable) are
available. The variable output includes a built-in volume
control; the fixed output does not.
The RECORD AUDIO and VIDEO OUTPUTS provide audio
and video output in the Record Zone. Two composite, two
S-video, two analog stereo (one fixed, one variable), one
S/PDIF coaxial, and one S/PDIF optical outputs are available.
The AES/EBU and S/PDIF INPUTS provide digital audio input.
One AES/EBU, six S/PDIF coaxial, and six S/PDIF optical
(including one optical mini jack) inputs are available.
The MICROPHONE INPUTS are provided for future expansion.
Four 3.5mm T/R/S or balanced inputs are available.
The TRIGGER OUTPUTS provide DC output. These outputs are
available on a removable terminal block. The PWR trigger is on
when the unit is on, and off when the unit is in standby or off.
Triggers 1 and 2 can be configured in the TRIGGER SETUP
menu (see page 3-35).
The RS-232 Connector labelled 1 is provided for serial control
and software upgrades. The RS-232 connector labelled 2 is
provided for future expansion.
The IR IN Connector is provided for input of infrared data
from industry-standard infrared distribution equipment. A
3.5mm T/R/S input is available.
A Removable Access Panel is provided for future expansion.
The VIDEO INPUTS provide video input in the Main and
Record Zones. Eight S-video, five composite video, and four
component video inputs are available in the Main Zone. All can
be assigned in the INPUT SETUP menu (see page 3-3). S-video
and composite video inputs are available in the Record Zone.
The AUDIO INPUTS provide analog audio input in all zones.
Eight stereo analog input pairs labeled 1 to 8 are available.
Pairs 6, 7, and 8 can be configured as a 5.1-channel analog
input. These pairs function as (L)/(R), (C)/(SUB), and (LS)/(RS)
when the 5.1-channel analog input is selected (see page 3-30).
The MAIN AUDIO OUTPUTS provide analog audio output in
the Main Zone. Ten outputs labeled FRONT L/R, CENTER, LFE,
SUBWOOFER L/R, SIDE L/R, and REAR L/R are available. The
AUX L/R outputs are reserved for future expansion.
The balanced MAIN and ZONE 2 AUDIO OUTPUTS provide
analog audio output in the Main Zone and Zone 2. Ten
outputs labeled FRONT L/R, CENTER, LFE, SUBWOOFER L/R,
SIDE L/R, and REAR L/R are available in the Main Zone. The
AUX L/R outputs are reserved for future expansion. Two
connectors labeled ZONE 2 L/R are available as a variable
stereo output for Zone 2.
The MAIN VIDEO OUTPUTS provide video output in the Main
Zone. One component (BNC), two composite, and two
S-video outputs are available. The component video output is
only available when component video inputs are used.
Composite video outputs are available when composite or
S-video inputs are used. S-video outputs are only available
when S-video inputs are used. Output 1 (OSD) incorporates
the on-screen display; output 2 does not.
2-5
Basic Operation
MC-12/MC-12 Balanced
