Lexicon MC-12 - REV 1 User Manual

3-31
The SETUP Menu
MC-12/MC-12 Balanced
DISPLAY SETUP
ON-SCREEN DISPLAY
FRONT PANEL DISPLAY
A/V SYNC DELAY OFF
CUSTOM NAME OFF
EDIT CUSTOM NAME
SETUP
INPUTS
SPEAKERS
REAR PANEL CONFIG
DISPLAYS
VOLUME CONTROLS
TRIGGERS
LOCK OPTIONS
DISPLAY SETUP
ON-SCREEN DISPLAY
Default
Parameter Value Values
STATUS 2 SECONDS ALWAYS ON, 2 SECONDS,
ALWAYS OFF
POSITION TOP TOP, CENTER, BOTTOM
FORMAT NTSC NTSC, PAL, SECAM
BACKGROUND ON ON, OFF
REMOTE STATE ON ON, OFF
SETUP DISPLAYS ON-SCREEN DISPLAY
STATUS (ALWAYS ON, 2 SECONDS, ALWAYS OFF)
STATUS activates and deactivates the on-screen display, provided
the display device is utilizing the MAIN VIDEO OUTPUT labelled 1
(OSD). When set to ALWAYS ON, the on-screen display remains on
at all times. When set to 2 SECONDS, the on-screen display will
appear for two seconds when the unit receives a command or the
input type changes. When set to ALWAYS OFF, the on-screen
display remains off at all times.
POSITION (TOP, CENTER, BOTTOM)
POSITION controls the vertical position of the two-line status (see
page 1-5) on the display device. When set to TOP, the two-line sta-
tus appears near the top of the display device screen. When set to
CENTER, the two-line status is centered on the display device
screen. This setting is recommended when the top and bottom of
the on-screen display appears cropped (not visible). When set to
BOTTOM, the two-line status appears near the bottom of the
display device screen.
MAIN MENU
MODE ADJUST
AUDIO CONTROLS
SETUP
ON-SCREEN DISPLAY
STATUS 2 SECONDS
POSITION TOP
FORMAT NTSC
BACKGROUND ON
REMOTE STATE ON
