Warning!
When you are drilling ,please make sure
you wear glasses and dust masks to
prevent the dust fly into the nose and throat
causing unnecessary trouble.
fig.1 fig.2 fig.3
fig.4
4
．
Put the power wire and load wire through the base holes
（
see fig.5
）
;
5
．
Cover cover into buckle
（
see fig.6
）
;
1
．
Through the buckle under cover(see fig.1)(fig2)
2
．
Hold base against the Ceiling and mark drill holes,
paying attention to any existing wiring in the Ceiling;
3
．
Drill the holes, insert wall plugs (6mm dia.);(see fig.4);
Parameter setting
Shown as chart below:By setting the S1, S2 ,S3 ,S4,S5 to set the delay time of products,by setting S6,S7 to
set the detection range of products, by setting the S8,S9,S10 to set the light-control of products.
fig.6fig.5
base holes
Installation
AC Power
L
L’
N
TIME:S3,S4,S5SENS:S1,S2 LUX:S6,S7,S8
S1
1
0
S2 S3 S4 S5 S6 S7 S8
To Next Page
