58D6056 7
A
C
B
DV20 DV30 DV40
A 20
7
/8"26
1
/2"29
1
/2"
B 23
1
/2"28
1
/2"30
1
/2"
C 18
3
/4" 21" 22"
Figure 2 - External Stove Dimensions
STOVE DIMENSIONS
PRE-INSTALLATION INFORMATION
