2 Squeeze and then slide the width guide to the correct position for the paper size you are loading.
3 Squeeze and then slide the length guide to the correct position for the paper size you are loading.
Note: The length guide has a locking device. To unlock, push the button on top of the length guide backward. To lock, push
the button forward when a length has been selected.
3
2
1
4 Flex the sheets back and forth to loosen them. Do not fold or crease the paper. Straighten the edges on a level surface.
5 Load the paper stack with the recommended print side faceup.
Printing guide
Page 2 of 3
