Replacing the ADF pick roller
1 Turn
o
the printer.
2 Open door D.
3 Remove the ADF pick roller cover.
4 Remove the ADF pick roller.
Warning—Potential Damage: Some parts of the printer are easily damaged by static electricity. Before
touching any parts or components in an area marked with the static‑sensitive symbol, touch a metal
surface in an area away from the symbol.
Maintaining the printer 190
