Lexus 2012 RX450h - Page 814

814
4-3. Do-it-yourself maintenance
13
DCDC 150 A
IG1 MAIN, TOWING BATT,
DEICER, TOWING, STOP, RDI FAN
NO. 1, ABS NO. 1, RR DEF, AIR SUS,
HEATER, RDI FAN NO. 2, H-LP
CLN, PBD, ECU-IG1 NO. 1, ECU-
IG1 NO. 3, GAUGE NO. 1, ECU-IG1
NO. 2, EPS, FR WIP, RR WIP, FR
WASH, RR WASH, RH S-HTR, LH S-
HTR, TAIL, PANEL, D/L ALT B, FR
FOG, FR DOOR, FL DOOR, RR
DOOR, RL DOOR, PSB, P-SEAT LH,
P-SEAT RH, TI&TE, AIR SUS, FUEL
OPN, DR LOCK, OBD, RR FOG, S/
ROOF, 4WD, INVERTER, ECU-
ACC, P/POINT, CIG, RADIO NO. 2
14
AMP1 30 A Audio system
15
EFI MAIN 30 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, EFI NO. 1, EFI NO. 2, F/PMP
16
AMP2 30 A Audio system
17
IG2 MAIN 30 A IGN, GAUGE NO. 2, ECU IG2
18
IP J/B 25 A Power door lock system
19
STR LOCK 20 A Starter system
20
RAD NO. 3 15 A
Meters and gauges, navigation sys-
tem, audio system
21
HAZ 15 A Emergency flashers
22
ETCS 10 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
23
RAD NO. 1 10 A Audio system, navigation system
Fuse Ampere Circuit
