Lexus 2012 RX450h - Page 820

820
4-3. Do-it-yourself maintenance
7
ECU-IG1 NO. 1 10 A
Multiplex communication system,
steering sensor, shift lock control sys-
tem, tilt and telescopic steering,
power back door, pre-collision sys-
tem, vehicle dynamics integrated
management, tire pressure warning
system
8
S/ROOF 30 A Moon roof
9
FUEL OPN 7.5 A Fuel filler door opener
10
PSB 30 A Pre-collision seat belt
11
TI & TE 30 A Tilt and telescopic steering system
12
DR LOCK 10 A
13
FR FOG 15 A Front fog lights
14
P-SEAT LH 30 A Power seat (left-side)
15
4WD 7. 5 A AWD system
16
INVERTER 20 A Power outlet
17
RR FOG 7.5 A
18
D/L ALT B 25 A
Multiplex communication system,
power door lock system, power back
door
19
EPS 10 A Electric power steering system
20
ECU-IG1 NO. 2 10 A
Intuitive parking assist, pre-collision
seat belt, capacitor
Fuse Ampere Circuit
