2-2. Instrument cluster
2
When driving
CT200h_U (OM76040U)
■ Cruising range
■ Elapsed time
■ Average vehicle speed
Displays the estimated maximum distance
that can be driven with the quantity of fuel
remaining.
• This distance is computed based on your
average fuel consumption.
As a result, the actual distance that can be
driven may differ from that displayed.
• When only a small amount of fuel is
added to the tank, the display may not be
updated.
When refueling, turn the “POWER”
switch off. If the vehicle is refueled with-
out turning the “POWER” switch off, the
display may not be updated.
Displays the elapsed time since the hybrid
system was started or the function was
reset.
The function can be reset by pressing the
“DISP” button for longer than 1 second when
the elapsed time is displayed.
Displays the average vehicle speed since
the function was reset
The function can be reset by pushing the
“DISP” button for longer than 1 second when
the average vehicle speed is displayed.
