Lexus CT200h - 12-Volt Battery

528
4-3. Do-it-yourself maintenance
CT200h_U (OM76040U)
12-volt battery
■ Location
The 12-volt battery is located in
the right-hand side of luggage
compartment.
■ Removing the 12-volt battery cover
Open the center and right side auxiliary boxes. (P. 462 )
Remove the center auxiliary box. (P. 6 3 2)
Remove the right side auxiliary
box.
Remove the 12-volt battery
maintenance cover.
STEP 1
STEP 2
STEP 3
STEP 4
