6-1. Specifications
CT200h_U (OM76040U)
Brakes
*
1
: Minimum pedal clearance when depressed with a force of 44.1 lbf (196 N,
20.0 kgf) while the hybrid system is operating.
*
2
: Parking brake pedal travel when depressed with a force of 67.5 lbf (300 N,
30.6 kgf).
m
Steering
Pedal clearance*
1
With Aluminum pedal
3.11 in. (79 mm) Min.
Without Aluminum pedal
3.03 in. (77mm) Min.
Pedal free play 0.04 0.24 in. (1.0 6.0 mm)
Brake pad wear limit 0.04 in. (1.0 mm)
Parking brake lining wear limit 0.04 in. (1.0 mm)
Parking brake pedal travel*
2
8 11 clicks
Fluid type SAE J1703 or FMVSS No. 116 DOT 3
Free play Less than 1.2 in. (30 mm)
