Lexus LFA - Page 293

291
4-3. Do-it-yourself maintenance
4
Maintenance and care
8
CDS FAN 40 A Electric cooling fan
9
WIP 40 A Windshield wiper
10
ABS MTR1 50 A Electronically controlled brake system
11
ACC CUT 7.5 A Starter system
12
H-LP RH 15 A Headlight low/high beam (right-side)
13
H-LP LH 15 A Headlight low/high beam (left-side)
14
E/G IG 5 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, ASG (Automated Sequential
Gearbox)
15
IGN 10 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, SRS airbag system, electronically
controlled brake system, electric
power control system
16
EFI NO.2 10 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
17
EFI NO.1 10 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
18
P/I 50 A INJ, A/PMP HTR, EFI, A/F HTR
19
ST 30 A Starter system
20
MAIN 30 A H-LP RH, H-LP LH
21
ABS MTR2 50 A Electronically controlled brake system
22
F/PMP 30 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
Fuse Ampere Circuit
