364
6-1. Specifications
Brakes
*
1
: Minimum horizontal distance between and when the pedal is depressed
with a force of 45 lbf (200 N, 20 kgf) while the engine is idling.
*
2
: Upper side of pedal cover
Pedal clearance*
1
4.0 in. (102 mm) Min.
Floor (firewall)
Brake pedal
Pedal cover
Pedal free play 0.04 0.08 in. (1.0 2.0 mm)
Brake pad wear limit 0.08 in. (2.0 mm)
Parking brake pad wear limit 0.06 in. (1.5 mm)
Fluid type FMVSS No.116 DOT 3 or SAE J1703
4.0 in. (102 mm) Min. 0.20 in. (5 mm) or less*
2
