Lexus LS 430 2004 - Immobilizer Function Registration - Part 2; Navigating Diagnostic Menus to Immobilizer Utility

REPAIR MANUAL SUPPLEMENT: SMART KEY REGISTRATION – EL003-04 Revised June 24, 2004
Page 4 of 9
WHEN THIS
SCREEN APPEARS:
1: DATA LIST
2: DTC INFO
3: ACTIVE TEST
4: SNAPSHOT
5: ID UTILITY
DIAGNOSTIC MENU
IMMOBILISER
5: ID UTILITY
DO THIS:
Select “IMMOBILISER”
Select “ID UTILITY”
Select “IMMOB CODE REG”
Press “YES”
E
F
G
H
(Continued from previous page)
1: ABS / VSC
2: CCS
3: AIR CONDITIONER
4: STEERING LOCK
5: SRS AIRBAG
6: GATEWAY
7: BODY NO.2
8: BODY NO.3
9: BODY NO.4
OBD/MOBD MENU
4: IMMOBILISER
1: TRANSP CODE REG
2: IMMOB CODE ERS
3: ECU COMM ID REG
ID UTILITY
IMMOBILISER
1: IMMOB CODE REG
9: IMMOB CODE RESET
NOTE:
If “Remaining Time” expires
before completion of any step,
please reattempt entire procedure
from screen “G.”
THIS FUNCTION WILL
REGISTER THE
IMMOBILISER CODE.
Do you wish to
continue the
registration?
PRESS [YES] or [NO]
(Continued next page)
Registration
Procedure:
Immobilizer
Function
(Continued)
