REPAIR MANUAL SUPPLEMENT: SMART KEY REGISTRATION – EL003-04 Revised June 24, 2004
Page 9 of 9
WHEN THIS
SCREEN APPEARS:
DO THIS:
I
H
(Continued from previous page)
NOTE:
Registration may take up to 5 seconds. Pressing any other
buttons or pressing “UNLOCK” again between steps “c” and
“d” may cause the process to fail, or cause Wireless to work,
but NOT Smart function.
Press “ENTER”
(Within 30 seconds)
a. Place the Diagnostic Tester on the
passenger seat.
b. Hold the new (unregistered) key in front of
the center of the steering wheel at
approximately mid–chest level.
c. Depress both the Lock and Unlock Buttons
simultaneously for 1 second
and release.
d. Depress the unlock button and release.
e. Wait for response from vehicle
(double chirp).
Please complete the
following operation
within 30 seconds.
–Press [ENTER].
–Hold both UNLOCK
and LOCK for one
second.
–Within 3 seconds,
press any button
on the key.
Remaining Time:
[27] seconds
Please perform the
button operation
from the previous
screen.
ID REGISTRATION
*NOW REGISTERING*
Remaining Time:
[ 6] seconds
[EXIT] to abort.
No action required
J
Please perform the
button operation
from the previous
screen.
<RESULT>
PRESS [YES] or [NO]
Registration was
completed.
If Immobiliser code
is not registered,
please execute
IMMOB CODE REG.
Do you want to
register another
Code?
If additional keys are to be
registered, press “YES”
END
10. Confirm that Wireless and Smart functions are working properly.
