197
2-4. Using other driving systems
2
When driving
The distance display and buzzer
When a sensor detects an obstacle, the direction of and the approximate
distance to the obstacle are displayed and the buzzer sounds.
■ Center sensors
■ Corner sensors and side sensors
Level 1 2 3 4
Display
example of
front center
sensor
Buzzer Slow Medium Fast Continuous
Level 1 2 3 4
Display
example of
front right
sensor
-
Buzzer - Medium Fast Continuous
