4-3. Do-it-yourself maintenance
8
RL SEAT 30 A Rear seat adjustment
9
B/ANC 10 A Shoulder anchor
10
RR S/SHADE 10 A Rear sunshade
11
PSB 30 A Pre-collision seat belt
12
PTL 30 A Power trunk opener and closer
13
FUEL OPN 15 A
Fuel filler door opener, power trunk
opener and closer
14
RR MPX-B 1 10 A
Audio system, rear seat entertainment
system, power trunk opener and
closer
15
RR MPX-B 2 5 A
Power door lock system, rear seat
adjustment, interior lights, power
trunk opener and closer, alarm
16
IGCT 3 5 A
17
BATT FAN 20 A Electric cooling fan
18
B-FAN RLY 5 A Electric cooling fan
19
RR ECU-B 5 A Seat belt buckle lights, trunk light
20
ABS MAIN 4 10 A Capacitor
21
STOP LP 1 10 A Stop lights, back-up lights
22
STOP LP 2 10 A Stop lights, high-mounted stoplights
23
TAI L 5 A Tail lights, license plate lights
24
E-PKB 30 A Brake system
Fuse Ampere Circuit
