924
8-1. Specifications
LS600h/LS600hL_EE(OM50D61E)
*: Minimum pedal clearance when depressed with a force of 500 N (51 kgf,
112 lbf) while the hybrid system is operating.
When performing the brake pedal inspection, also be sure to check that the
brake system warning light is not illuminated when the hybrid system is
operating (If the brake system warning light is illuminated, refer to P.
851).
Brakes
Pedal clearance* 147 mm (5.8 in.) Min.
Pedal free play 1.0 - 2.0 mm (0.04 - 0.08 in.)
Fluid type
SAE J1703 or FMVSS No.116 DOT 3 or,
SAE J1704 or FMVSS No.116 DOT 4
Steering
Free play Less than 30 mm (1.2 in.)
Tires and wheels
Tire size 245/45R19 102Y
Tire inflation pres-
sure
(Recommended
cold tire inflation
pressure)
Vehicle speed Front wheel
kPa (kgf/cm
2
or bar, psi)
Rear wheel
kPa (kgf/cm
2
or bar, psi)
More than 210 km/
h (132 mph)
290 (2.9, 42) 290 (2.9, 42)
210 km/h
(132 mph) or less
250 (2.5, 36) 250 (2.5, 36)
Wheel size 19 8 J
Wheel nut torque 140 N•m (14.3 kgf•m, 103 ft•lbf)
To Next Page
