520
7-3. Do-it-yourself maintenance
RC350_RC300_RC200t_RC F_U (OM24671U)
Remove the fuse with the pullout
tool.
Only type A fuses can be removed
using the pullout tool.
Check if the fuse is blown.
Normal fuse
Blown fuse
Type A and B:
Replace the blown fuse with a new fuse of an appropriate amperage rating. The
amperage rating can be found on the fuse box lid.
Type C and D:
Contact your Lexus dealer.
3
4
1
2
 Type A  Ty p e B
 Type C  Type D
