93
2. Instrument cluster
2
Instrument cluster
RC350_RC300_RC200t_RC F_U (OM24671U)
Main meter moved to the right
The units used on the meters may differ depending on the target region.
Engine coolant temperature gauge
Displays the engine coolant temperature
Tachometer
Displays the engine speed in revolutions per minute
Outside temperature
Displays the outside temperature within the range of -40°F (-40°C) to 122°F
(50°C). Low outside temperature indicator comes on when the ambient tempera-
ture is 37°F (3°C) or lower.
Shift position and gear position (P. 205)
Speedometer
Fuel gauge
Multi-information display
Presents the driver with a variety of vehicle data (P. 1 05)
Displays warning messages in case of a malfunction (P. 549)
Odometer and trip meter display
Odometer:
Displays the total distance the vehicle has been driven
Tri p me te r :
Displays the distance the vehicle has been driven since the meter was last reset.
Trip meters “A” and “B” can be used to record and display different distances inde-
pendently.
1
2
8
