93
2. Instrument cluster
2
Instrument cluster
RC F
● TVD (Torque Vectoring Differential) control mode indicators (RC F)
*
1
: These lights turn on when the engine switch is turned to IGNITION ON mode to
indicate that a system check is being performed. They will turn off after the engine is
started, or after a few seconds. There may be a malfunction in a system if a light does
not come on, or turn off. Have the vehicle inspected by your Lexus dealer.
*
2
: The light flashes to indicate that the system is operating.
*
3
: The light comes on when the system is turned off. The light will flash quickly when the
system is operating.
*
4
: In order to confirm operation, the BSM outside rear view mirror indicators illuminate
in the following situations:
• When the engine switch is turned to IGNITION ON mode while the BSM main
switch is turned on.
• When the BSM main switch is turned on while the engine switch is in IGNITION
ON mode.
If the system is functioning correctly, the BSM outside rear view mirror indicators will
turn off after a few seconds.
If the BSM outside rear view mirror indicators do not illuminate or do not turn off,
there may be a malfunction in the system.
If this occurs, have the vehicle inspected by your Lexus dealer.
*
5
: When the outside temperature is approximately 37°F (3°C) or lower, the indicator
will flash for approximately 10 seconds, then stay on.
*
6
: This light illuminates on the outside rear view mirrors.
*
7
: This light illuminates on the center panel.
*
8
:RC F
“NORMAL” indicator
(→P. 294)
Eco drive mode indicator
(→P. 294)
“SPORT S” indicator
(→P. 294)
“SPORT S+” indicator
(→P. 294)
Snow mode indicator
(→P. 214)
(if equipped)
“STANDARD” indicator
(→P. 329)
(if equipped)
“SLALOM” indicator
(→P. 329)
(if equipped)
“TRACK” indicator
(→P. 329)
