Lexus RX300 - Page 283

ELECTRICAL COMPONENTS
268
No.
FUSE
AMPERE
CIRCUIT
17
H–LP R
UPR
15
Right–hand headlight (high beam)
18
H–LP L
UPR
15
Left–hand headlight (high beam)
19
A/F HTR 25 Air fuel ratio sensor
20
IGN 7.5
SRS, Multiport fuel
injection/Sequential multiport fuel
injection system
21
RAD NO.2 7.5 Audio system, Multiplex computer
22
CIG 15
Cigarette lighter, Outside rear view
mirrors, Power door lock system
23
D. RR
DOOR
20
Rear door lock, Rear power
window
24
PWR
OUTLET
15
Power outlets
25
FR FOG 15 Fog lights
26
SRS–ACC 15 SRS
27
ECU–IG 15
Telephone, Inside rear view mirror,
Anti–lock brake system, Traction
control system, Multi–display
28
WIPER 25 Windshield wipers
29
P RR
DOOR
20
Rear door lock, Rear power
window
No.
FUSE
AMPERE
CIRCUIT
30
P FR
DOOR
20
Front door lock, Front power
window
31
S/ROOF 20 Moon roof
32
HEATER 15 Air conditioning system
33
GAUGE 7.5
Multiplex computer, Service
reminder indicators
34
RR WIP 15 Rear window wiper
35
STOP 20
Stop lights, High mounted
stoplight, Anti–lock brake system,
Traction control system
36
OBD 7.5 On–board diagnosis system
37
SEAT HTR 15 Seat heater system
38
STARTER 7.5 Starting system
39
WASHER 10 Washer
40
RR FOG 7.5 No circuit
41
FR DEF 20
Rear window and outside rear
view mirror defogger
42
SRS–B 7.5 SRS
43
TAIL 10
Tail lights, Side marker lights,
License plate lights, Parking lights
44
PANEL 7.5 Instrument panel lights
45
ABS 60 Anti–lock brake system
46
ALT 140 Charging system
No.
FUSE
AMPERE
CIRCUIT
47
RDI 40 Cooling fan system
