LG 15LS1R Service Manual

- 6 -
SPECIFICATION
LGE Internal Use OnlyCopyright © 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
1. Application range
This specification is applied to CL-81 chassis.
2. Requirement for Test
Testing for standard of each part must be followed in below condition.
(1) Temperature: 25°C ± 2°C
(2) Humidity: 65% ± 10%
(3) Power: Standard input voltage (AC 100-240V, 50/60Hz)
(4) Measurement must be performed after heat-run more than 30min.
(5) Adjusting standard for this chassis is followed a special standard.
3. General Specification
NOTE : Specifications and others are subject to change without notice for improvement .
No.
Item Content Remark
1
2
3
4
5
6
7
8
9
8Keys
NATION
LPL
LC150X02-TL01
Brand
15LS1R-MG
North America
15” LCD-TV
CL-81
Channel(
D,E), Volume(F,G), OK, Menu, Input, Power
Length : 1.87 ± 0.04 M
Shape : Wall-out
Color : BLACK
No
Maker LPL
Type TFT Color LCD Module
Active Display Area 15.0 inches(380.16mm) diagonal(Aspect 4:3)
Pixel Pitch [mm] 0.297mm(H)x0.297mm(V)x RGB
Electrical Interface LVDS
Color Depth 6BIT, 16,777,216 colors
Size [mm] 332.8(H) x 262.2(V) x 18(D)
Surface Treatment Anti-Glare(HAZE 3%), Hard Coating(3H)
Operating Mode Normally Black
Back light Unit 4 CCFL(4 lamps)
R/T Typ. R.T.: 5ms + F.T.: 11ms(Typ)
Customer
User Model Name
Sale region
Feature
Chassis Name
General Scope External SW & Adj.
Power Cord
Power Adapter
LCD Module Feature
