Only for training and service purposes

- 8 -

6.Engineering Specification

6-1.General Specification

No Item Specification Remark

1 ENERGY SYNC(V/H) VIDEO POWER CONSUMPTION LED COLOR

Normal On/On Active ≤ 40W BLUE

Sleep Mode Off/On

(PC Mode) On/Off Off ≤ 1W Amber

Off/Off

Off Mode - Off ≤ 1W Off(PC)

Amber(TV/AV)

2 D-SUB 1 : RED 2 : GREEN 10 : DIGITAL GND

Pin configuration 3 : BLUE 4 : ID2 (GND)

5 : S.T (GND) 6 : RED

7 : GREEN GND 8 : BLUE GND

9 : N.C 10 : D-GND

11 : ID0(GND) 12 : SDA

13 : H-SYNC 14 : V-SYNC

15 : SCL SHELL : GND

3 Control Function 1) Contrast / Brightness

2) H-Position

3) Tracking : Clock / Phase

4) Auto Configure

5) Reset
