SERVICE TEST PROGRAM
1. Test Items
(MICOM : 1.3.0, ROMFS : 1.2 12/21 ENG), TX SSID : 80035E
(Rx Micom/Rx Flash/ Version Display), TX SSID display
- LED : Rx LED Operation Test
- Volume : Speaker Operation Test/Headphone Operation
Test(for headphone connection)
- Brightness/Contrast : Rx SVC Mode Brightness/Contrast control
- Button : Rx Key Control Operation Test
- Remocon : Remocon Operation Test
- Battery : Battery information display
- RX Longrun : Audio(Continuous Tone)/ Video(straight Color Bar)
- RX Factory Default : RX Flash Data Initialization: Volume,
Brightness
- Initialize SSID : Initialization of TX SSID connected with RX
- TX : Tx SSID Display/VCTI,Tx Flash Version Display Long
Run/Tx VCTI Data Initialization
- S/W Upgrade : Execute Rx Flash Update through AP(Access
Point)
- Canadian VCHIP : Default(No)
- Dot Defect : Full Black/White Pattern to check Dot Defect of the
LCD module
2. SSID input screen
* Screen appearing where SSID is not saved
(1) Test initial screen
- Method to enter into the test screen
: Click the IN-START button of the Adjust Remocon (P/N:105-
201M) in the RX Power ON status(operable 10 seconds after On).
=> Click the Enter button of the REMOCON in order to select
detailed menu
(2) LED Test
- LED Operation Test of Rx
=> Click the Exit button of the REMOCON to return to the
previous initialization menu
(3) VOLUME Test
- Speaker Operation Test
=> Click the Exit button of the REMOCON to return to the
previous initialization menu
Press 'Select' to confirm, 'Exit' to retry
LWTV_8002FE
LWTV_8002EA
Test Items
(MICOM : 1.3.0, ROMFS :
1.2 12/21 ENG), TX SSID :
80035E
* LED
* Volume
* Brightness/Contrast
* Button
* Remocon
* Battery
* RX Longrun
* RX Factory Default
* Initialize SSID
* TX
* S/W Upgrade
* Canadian VCHIP :
* Dot Defect
Version
(Micom/CPU)
Test Items
(MICOM : 1.3.0, ROMFS :
1.2 12/21 ENG), TX SSID :
80035E
* LED
* Volume
* Brightness/Contrast
* Button
* Remocon
* Battery
* RX Longrun
* RX Factory Default
* Initialize SSID
* TX
* S/W Upgrade
* Canadian VCHIP :
* Dot Defect
Version
(Micom/CPU)
Blinking in blue color
Blinking in
Green color
Blinking in Yellow/Green color
Check LEDs are blinking
- Power LED (Blue)
- W-LAN LED (Green)
- Battery LED (Yellow/Green)
Volume is played in the level of 80 values.
Volume Testing..
Current Vol : 80
Test Items
(MICOM : 1.3.0, ROMFS :
1.2 12/21 ENG), TX SSID :
80035E
* LED
* Volume
* Brightness/Contrast
* Button
* Remocon
* Battery
* RX Longrun
* RX Factory Default
* Initialize SSID
* TX
* S/W Upgrade
* Canadian VCHIP :
* Dot Defect
