8
ENGLISH
PREPARATION
STAND INSTALLATION
(Only 19/22LS4D
*
)
■
Image shown may differ from your TV.
1
2
3
4
Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
Hold the
HHiinnggee BBooddyy
and bend it upward.
Hinge Body
Insert the
SSttaanndd BBooddyy
into the TV until clicking
sound.
Assemble the parts of the
SSttaanndd BBooddyy
with
the
CCoovveerr BBaassee
of the TV.
Cover Base
Stand Body
DETACHING STAND
(Only 19/22LS4D
*
)
1
2
3
Place the tv with its front facing downward on a
cushion or soft cloth.
Pull
the
CCoovveerr BBaassee
backward during pressing
a button on the
SSttaanndd BBooddyy
.
Hold
the
CCoovveerr BBaassee
and pull with shake it
backward to separate from the
SSttaanndd BBooddyy
.
4
Hold the
SSttaanndd BBooddyy
and bend it upward.
5
Pull stand body to separate from the TV during
pressing 2 latches.
To Next Page
