BACK COVER FOR WIRE ARRANGEMENT
LCD TV Models:
32/37/42LG20
**
, 26/32/37/ 42LG30
**
,
32/42LG32
**
, 32/37/42/47/52LG5
***
Connect the cables as neces-
sary.
To connect additional equip-
ment, see the External
Equipment Setup section of
the manual.
1
Open the
CCAABBLLEE MMAANNAAGGEEMMEENNTT CCLLIIPP
as
shown and manage the cables.
2
CABLE MANAGEMENT CLIP
Fit the
CCAABBLLEE MMAANNAAGGEEMMEENNTT CCLLIIPP
as
shown.
3
Connect the cables as necessary.
To connect additional equipment, see the
External Equipment Setup section.
1
Install the CABLE MANAGEMENT CLIP as shown.
(Only 19/22LS4D
*
)
(Only 19/22LG30
**
)
2
First, press the cable management. Hold the
CCAABBLLEE
MMAANNAAGGEEMMEENNTT CCLLIIPP
with both hands and pull it
upward.
NOTE
GG
Do not use the CABLE MANAGEMENT CLIP to lift the TV.
- If the TV is dropped, you may be injured or the TV may be damaged.
How to remove the cable management clip
LCD TV Models :
19/22LS4D
*
, 19/22LG30
**
(Only 19/22LS4D
*
)
Hold the CABLE MANAGEMENT CLIP with both
hands and pull it backward.
(Only 19/22LG30
**
)
To Next Page
