5. Chroma& Brightness (Optical)
(1) LCD Module
The Color Coordinates check condition
- 50cm from the surface, Full White Pattern
- Picture mode Vivid
- 7 -
LGE Internal Use OnlyCopyright © 2010 LG Electronics. Inc. All right reserved.
Only for training and service purposes
No. Item Min. Typ. Max. Unit Maker Remark
1. Luminance 280 350 cd/m
2
(W/O PC mode)
2. VIew angle (R/L, U/D) 170/155 degree CR > 10
3. Color Coordinates White X Typ 0.285 Typ
Y -0.03 0.293 +0.03
RED X 0.642
Y 0.333
Green X 0.295
Y 0.608
Blue X 0.147
Y 0.063
4. Contrast ratio 700:1 1000:1
5. Luminance Variation 1.3
6. Component Video Input (Y, PB, PR)
No.
Specification
Proposed
Resolution H-freq(kHz) V-freq(Hz) Pixel Clock(MHz)
1 720*480 15.73 59.94 13.500 SDTV, DVD 480I(525I)
2 720*480 15.75 60.00 13.514 SDTV, DVD 480I(525I)
3 720*576 15.625 50.00 13.500 SDTV, DVD 576I(625I) 50 Hz
4 720*480 31.47 59.94 27.000 SDTV 480P
5 720*480 31.50 60.00 27.027 SDTV 480P
6 720*576 31.25 50.00 27.000 SDTV 576P 50 Hz
7 1280*720 44.96 59.94 74.176 HDTV 720P
8 1280*720 45.00 60.00 74.250 HDTV 720P
9 1280*720 37.50 50.00 74.25 HDTV 720P 50 Hz
7. HDMI Input(DTV)
No.
Specification
Proposed Remarks
Resolution H-freq(kHz) V-freq(Hz) Pixel Clock(MHz)
1 720*480 15.73 59.94 13.500 SDTV, DVD 480I(525I) Spec. out
2 720*480 15.75 60.00 13.514 SDTV, DVD 480I(525I) but display
3 720*576 15.625 50.00 13.500 SDTV, DVD 576I(625I) 50 Hz
4 720*480 31.47 59.94 27 SDTV 480P
5 720*480 31.5 60.00 27.027 SDTV 480P
6 720*576 31.25 50.00 27 SDTV 576P
7 1280*720 44.96 59.94 74.176 HDTV 720P
8 1280*720 45 60.00 74.25 HDTV 720P
9 1280*720 37.5 50.00 74.25 HDTV 720P
