1 Viewing Angle R/L 80/80
<CR≥10> U/D 75/85
2 Luminance Luminance (cd/m
2
) 190 250 PMS:Dynamic, CSM:Cool, White(100 IRE)
3 Contrast Ratio CR 500 800 All white / All black
4 CIE Color Coordinates WHITE Wx Typ. 0.285 Typ.
Wy -0.015 0.293 +0.015 PMS : Dynamic
RED Rx 0.635 CSM : Cool
Ry 0.342 White(85 IRE)
GREEN Gx 0.292
Gy 0.611
BLUE Bx 0.147
By 0.070
4. Module Specification
4.1. 22” LCD MODULE (LPL LM220WE1-TLA1)
4.2. Electro optical characteristic specifications(module standard)
- 7 -
1. Display area 473.76 (H) x 296.1 (V) mm
2. Outline dimension 493.7 (H) x 320.1 (V) x 16.5 (D) mm Max
3. Number of Pixels 1680 (H) x 1050 (V) 1Pixel=3RGB Cells
4. Cell pitch 0.282mm (H) x 0.282mm (V) mm 1Pixel=3RGB Cells
5. Color arrangement RGB vertical stripe
6. Weight(net) 2.8 Kg
7. Operating Environment Temperature 0 ~ 50 deg
Humidity 10 ~ 90 %
8 Storage Environment Temperature -20 ~ 60 deg
Humidity 10 ~ 90 %
9 Electrical Interface LVDS
10 Back light Unit 4 CCFL (4 lamps)
11 Response Time 5ms Typ.
No. Item Min Typ. Max Unit Remark
No. Item
Specification
Min Typ. Max
Remark
