- 8 -
6. Component Video Input (Y, P
B
, P
R
)
No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed
1 720*480 15.73 59.94 13.500 SDTV, DVD 480I(525I)
2 720*480 15.75 60.00 13.514 SDTV, DVD 480I(525I)
3 720*576 15.625 50.00 13.500 SDTV, DVD 576I(625I)
4 720*480 31.47 59.94 27.000 SDTV 480P
5 720*480 31.50 60.00 27.027 SDTV 480P
6 720*576 31.25 50.00 27.000 SDTV 576P
7 1280*720 44.96 59.94 74.176 HDTV 720P
8 1280*720 45.00 60.00 74.250 HDTV 720P
9 1280*720 37.50 50.00 74.250 HDTV 720P 50Hz
10 1920*1080 33.72 59.94 74.176 HDTV 1080I
11 1920*1080 33.75 60.00 74.250 HDTV 1080I
12 1920*1080 28.125 50.00 74.250 HDTV 1080I 50Hz
7. RGB Input (PC)
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remark
1 640*480 31.469 59.94 25.17 VESA(VGA)
2 800*600 37.879 60.31 40.00 VESA(SVGA)
3 1024*768 48.363 60.00 65.00 VESA(XGA)
4 1280*1024 63.981 60.02 108.0 VESA(WXGA)
5 1440*900 55.5 59.90 88.75 WXGA+ 19LS4R-TA only
6 1680*1050 65.290 59.954 146.25 WXGA+ 22LS4R-TA only
5. Model Specification
No Item Specification Remark
1 Market Non-EU
2 Broadcasting system PAL BG/DK, I, NTSC-M, SECAM BG/DK
3 RF Input Channel VHF/ UHF : C1 ~ C69PAL
CATV : S1 ~ S47
VHF/ UHF : 2 ~ 83 NTSC
CATV : 1 ~ 71
4 Video Input (1EA) PAL, SECAM, NTSC 4 System(Rear) :PAL50, SECAM, NTSC, PAL60
5 S-Video Input (1EA) PAL, SECAM, NTSC 4 System(Rear) :PAL50, SECAM, NTSC, PAL60
6 Component Input (1EA) Y/ Pb/Pr 480i/576i/567P/480P/720P/1080i
7 RGB Input (1EA) RGB-PC, RGB-DTV
8 HDMI Input (1EA) HDMI-PC
HDMI-DTV
9 Audio Input (2EA) 2EA : CVBS, PC Audio L/R Input
