LG 22LS4R User Manual

- 9 -
8. RGB input ( DTV )
No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed
1 720*480 31.47 59.94 27.000 SDTV 480P
2 720*480 31.50 60.00 27.027 SDTV 480P
3 720*576 31.25 50.00 27.000 SDTV 576P
4 1280*720 37.5 50.00 74.250 HDTV 720P 50Hz
5 1280*720 44.96 59.94 74.176 HDTV 720P
6 1280*720 45.00 60.00 74.250 HDTV 720P
7 1920*1080 33.72 59.94 74.176 HDTV 1080I
8 1920*1080 33.75 60.00 74.250 HDTV 1080I
9 1920*1080 28.125 50.00 74.250 HDTV 1080I 50Hz
10. HDMI/DVI input (DTV)
No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed
1. 720*480 31.47 59.94 27.000 SDTV 480P
2. 720*480 31.50 60.00 27.027 SDTV 480P
3. 720*576 31.25 50.00 27.000 SDTV 576P
4. 1280*720 37.5 50.00 74.250 HDTV 720P 50Hz
5. 1280*720 44.96 59.94 74.176 HDTV 720P
6. 1280*720 45.00 60.00 74.250 HDTV 720P
7. 1920*1080 33.72 59.94 74.176 HDTV 1080I
8. 1920*1080 33.75 60.00 74.250 HDTV 1080I
9. 1920*1080 28.125 50.00 74.250 HDTV 1080I 50Hz
9. HDMI/DVI input (PC)
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remark
1 640*480 31.469 59.94 25.17 VESA(VGA)
2 800*600 37.879 60.31 40.00 VESA(SVGA)
3 1024*768 48.363 60.00 65.00 VESA(XGA)
4 1280*1024 63.981 60.02 108.0 VESA(WXGA)
5 1440*900 55.5 59.90 88.75 WXGA+ 19LS4R-TA only
6 1680*1050 65.290 59.954 146.25 WXGA+ 22LS4R-TA only

LG 22LS4R Specifications

General

Brand	LG
Model	22LS4R
Category	LCD TV
Language	English
