LG 22MT57D - Page 21

17
ENGENGLISH
RGB (PC) / HDMI (PC) supported mode
22/24/27MT57D , 22MT47D
Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
720 x 400 31.468 70.080
640 x 480
31.469
37.500
59.940
75.000
800 x 600
37.879
46.875
60.317
75.000
1024 x 768 48.363 60.004
1024 x 768
(Only HDMI(PC))
56.476 70.069
1024 x 768 60.023 75.029
1152 x 864 67.500 75.000
1280 x 720 45.000 60.000
1280 x 800 49.702 59.810
1280 x 1024
63.981
79.976
60.020
75.025
1400 x 1050 65.317 59.978
1440 x 900 55.935 59.887
1600 x 900 60.000 60.000
1680 x 1050
64.674
65.290
59.883
59.954
1920 x 1080 67.500 60.000
24/28MT47D
Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
720 x 400 31.468 70.080
640 x 480
31.469
37.500
59.940
75.000
800 x 600
37.879
46.875
60.317
75.000
1024 x 768
48.363
60.023
60.004
75.029
1280 x 800 49.702 59.810
1366 x 768 47.717 59.79
NOTE
• The optimal display resolution
- 22/24/27MT57D, 22MT47D: 1920 X 1080 @ 60 Hz.
- 24/28MT47D: 1366 X 768 @ 60 Hz.
• The optimal timing in each mode is vertical frequency 60 Hz.
HDMI (DTV) supported mode
Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
720 x 480
31.469
31.5000
59.940
60.000
720 x 576 31.250 50.000
1280 x 720
37.500
44.960
45.000
50.000
59.940
60.000
1920 x 1080
33.720
33.750
28.125
27.000
33.750
56.250
67.430
67.500
59.940
60.000
50.000
24.000
30.000
50.000
59.940
60.000
Component supported mode
Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
720 x 480
15.730
15.750
31.470
31.500
59.940
60.000
59.940
60.000
720 x 576
15.625
31.250
50.000
50.000
1280 x 720
44.960
45.000
37.500
59.940
60.000
50.000
1920 x 1080
33.720
33.750
28.125
56.250
67.432
67.500
59.940
60.000
50.000
50.000
59.940
60.000
Component port connecting information
Component ports on the TV
Y P
B
P
R
Video output ports
on DVD player
Y P
B
P
R
Y B-Y R-Y
Y Cb Cr
Y Pb Pr
