LG 28LW750H-ZA User Manual

ENG
ENGLISH
50
EXTERNAL CONTROL DEVICE SETUP
RS-232C Congurations
7-Wire Configurations
(Standard RS-232C cable)
3-Wire Configurations
(Not standard)
Set ID
Set ID number. “Real Data Mapping”.
1 Press SETTINGS or HOME to access the
main menus.
2 Press the Navigation buttons to scroll to
OPTION and press OK.
3 Press the Navigation buttons to scroll to Set
ID and press OK.
4 Scroll left or right to select a set ID number
and select Close. The adjustment range is
1-99.
5 When you are nished, press EXIT.
PC TV
2 3
3 2
5 5
4 6
6 4
7 8
8 7
D-Sub 9 D-Sub 9
RXD
TXD
GND
DTR
DSR
RTS
CTS
TXD
RXD
GND
DSR
DTR
CTS
RTS
PC TV
2 3
3 2
5 5
4 6
6 4
7 7
8 8
D-Sub 9 D-Sub 9
RXD
TXD
GND
DTR
DSR
RTS
CTS
TXD
RXD
GND
DTR
DSR
RTS
CTS

LG 28LW750H-ZA Specifications

General

USB Ports	1
Smart TV	Yes
Built-in Wi-Fi	Yes
Screen Size	28 inches
Display Type	LED
Connectivity	HDMI, USB, Component, Composite, RF, Ethernet
Energy Efficiency Class	A
