LG 32FS4D - Service Mode Data (NEC & MST3000 ICs)

- 16 -
14-4. NEC IC(uPD64015)
NO ITEM NO ITEM
1 YCORB 0 21 CTIGAIN 7
2 YCOREN 1 22 LTITAP 2
3 YCORB2 0 23 LTICORE 3
4 CRDLY 0 24 CTITAP 6
5 YGCAVAL 9 25 CTICORE 3
6 DYCOR 2 26 SHPGAIN 160->140
7 DYGAIN 9 27 SHPCHAR 0
8 DCCOR 3 28 SHPCORE 0
9 DCGAIN 6 29 BRIGHT 130->126
10 VAPG 7->3 30 OFRY 32
11 VAPI 4->20 31 BRIGHT 0
12 YNRS 0 32 COLOR 128
13 CNRS 0 33 HUE 128
14 DLYCTL 8 34 CONT 124
15 bSBCNT 128 35 YGCAUTO 1
16 SBCLRU 128 36 YGCVAL 62
17 SBCLRV 128 37 CBOFS 1
18 YVRCORE 0->2 38 CROFS 2
19 CNRCORE 0->2 39 YGCOFF 0
20 LTIGAIN 1- 40
Initial data
Initial data
14-5. MST3000(ADC_IC)
NO ITEM NO ITEM
1 CHIP_REVISION 0 32 RED_CLAMP_SEL 0
2 PLL_DIV_MSB 105 33 GREEN_CLAMP_SEL 0
3 PLL_DIV_LSB 13 34 BLUE_CLAMP_SEL 0
4 VCO_RANGE 1 35 SYNC_SEPARATOR 32
5 CHARGE_PUMP_CURRE 1 36 PRE_COAST 0
6 PHASE_ADJUST 0 37 POST_COAST 0
7 CLAMP_PLACEMENT 16 38
8 CLAMP_DURATION 8 39
9 HSYNC_OUTPUT_PULS 32 40
10 RED_GAIN 172
41
11 GREEN_GAIN 199
42
12 BLUE_GAIN 168
43
13 RED_OFFSET 62
44
14 GREEN_OFFSET 48
45
15 BLUE_OFFSET 62
46
16 HSYNC_POLARITY 0 47
17 HSYNC_INPUT_POL 1 48
18 HSYNC_OUTPUT_POL 0 49
19 ACTIVE_HSYNC_OVER 0 50
Initial data
Initial data
