* Input Select Data
RF(10), AV1~4(20,21,22,23), SAV(30), COMP(40),
DVI(50or60), HDMI(90)
* Command Set (SET ID : 0-> ALL , 1~99 -> each SET)
7. Detail list of SVC option data
- 14 -
POWER ON/OFF
MAIN INPUT
ARC
SCREEN MUTE
AUDIO MUTE
VOLUME
CONTRAST
BRIGHTNESS
COLOR
TINT
SHARPNESS
OSD ON/OFF
CHILD LOCK
PIP MODE
PIP ARC
PIP POSITION
TREBLE
BASS
BALANCE
COLOR TEMP.
RED LEVEL
GREEN LEVEL
BLUE LEVEL
PIP INPUT
CURRENT STATE
Adjustment CMD SET ID VAL Remark
KA(ka)
XB(xb)
KC(kc)
KD(kd)
KE(ke)
KF(kf)
KG(kg)
KH(kh)
KI(ki)
KJ(kj)
KK(kk)
KL(kl)
KM(km)
KN(kn)
KO(ko)
KQ(kq)
KR(kr)
KS(ks)
KT(kt)
KU(ku)
KV(kv)
KW(kw)
K$(k$)
XY(xy)
KZ(kz)
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~1
10~90
0~6
0~1
0~1
0~64
0~64
0~64
0~64
0~64
0~64
0~1
0~1
0~3
0~64
0~64
0~64
0~3
0~60
0~60
0~60
10~90
FF
0: OFF, 1:ON
RF(10), AV1~4(20,21,22,23),
SAV(30), COMP(40),
RGB(50 or 60), HDMI(90)
SPECTACLE, FULL, ORIGINAL
4:3, 16:9, 14:9, ZOOM
0: MUTE, 1: MUTE OFF
0: MUTE, 1: MUTE OFF
0: 0, 64 : 100 (Hexadecimal)
0: 0, 64 : 100 (Hexadecimal)
0: 0, 64 : 100 (Hexadecimal)
0: 0, 64 : 100 (Hexadecimal)
0: R50, 64 : G50 (Hexadecimal)
0: 0, 64 : 100 (Hexadecimal)
0: OFF, 1: ON
0: LOCK, 1: OFF
PIP_OFF, PIP, DW1, DW2
NOT USED
NOT USED
0:0, 64:100
0:0, 64:100
0:L50, 64:R50
COOL, NORMAL, WARM, USER
0 : -30, 60 : 30
0 : -30, 60 : 30
0 : -30, 60 : 30
RF(10), AV1~4(20,21,22,23),
SAV(30), COMP(41),
DVI(50 or 60), ,HDMI(61)
ACK : 0 - With signal
ACK : 1 -> Without signal
ACK : 2 -> Power Off
Tool Option1
Tool Option2
Area Option1
Option
Option2
Option3
Option4
Option Detail list Data
Side AV
BOOST
Woofer
SoundSettings
Tuner Num.
EYE
INDEX
VFD
FULL
HDMI Type (S or A)
200PR
ACMS
TEXT
CH+AU
SYS
A2 ST
I II SAVE
HDEV
V-Curve
MONO
Scart
CSM
Default Lang.
LANG
T LANG
0/1
0/1
0/1
32LB/37LB
No/1/2 Tuner
0/1
0/1
0/1
0/1
None/1-HDMI/2-HDMI
0/1
0/1
Off/Top/Flop
0/1
BGIDKL / BGIDKM
0/1
0/1
0/1
0/1
0/1
2 Scarts / 2 Components
Normal / Warm / Cool
English
EU-ALL/ EU / EU-8/ EU-North
/ EU-East/ Non-EU 8/ Non-EU etc
0~4
White Balanc“J”(A~F)
RED GAIN
GREEN GAIN
BLUE GAIN
RED OFFSET
GREEN OFFSET
BLUE OFFSET
AUTO CONFIG.
TUNER CONTROL
SELECT PR.
SELECT SUB PR.
FACTORY IR
IR CODE
ADC Calriblation
Red,Blue,Green
Gain
Red,Blue,Green
offset
Adjustment CMD SET ID VAL Remark
JA
JB
JC
JD
JE
JF
JU
MA
MB
MC
Ja,Jb,Jc
Jd,Je,Jf
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
0~99
direction
:00<E0
00<90
0~3F
0~3F
0~3F
0~3F
0~3F
0~3F
01
0~C7
0~C7
- F0
Min:00
Max:fe
Min:00
Max:fe
0:0, 3F:3F, FF : the state marking
0:0, 3F:3F, FF :the state marking
0:0, 3F:3F, FF : the state marking
0:0, 3F:3F, FF : the state marking
0:0, 3F:3, FF : the state marking
0:0, 3F:3F, FF : the state marking
If Auto Adjust Condition is not,
send the NACK.
0: Pr. 0, C7: Pr.199
0: Pr. 0, C7: Pr.199
IR CODE 0, BITMASK = 0X01
Initial data : red -0x79
blue -0x6f
green -0x80
Initial data : red -0x80
blue -0x82
green -0x80
