LG 32LB9D - Desktop Pedestal Installation; Vesa Wall Mounting

PREPARATION
17
DESKTOP PEDESTAL INSTALLATION
For proper ventilation, allow a clearance of 4inches on all four sides from the wall.
4 inches
4 inches
47LC7DF
4 inches
4 inches
4 inches
4 inches
50/60PY3D
4 inches
4 inches
4 inches
4 inches
32LB9D
4 inches
4 inches
VESA WALL MOUNTING
This product accepts a VESA-compliant mounting interface pad. (optional)
There 4 threaded holes are available for attaching the bracket.
GG
Screw length needed depends on the wall mount used. For further information, refer to the VESA
Wall Mounting Instruction Guide.
NOTE
47LC7DF
32LB9D
AV IN 2
L/ MONO
R
AUDIO
VIDEO
USB IN
100mm
400mm
200mm
600mm
50/60PY3D
AV IN 2
L/ MONO
R
AUDIO
VIDEO
S-VIDEO
USB
400mm
600mm
