13
PREPARATION
WALL MOUNT: HORIZONTAL INSTALLATION
For proper ventilation, allow a clearance of 4" on each side and from the wall. Detailed installation instruc-
tions are available from your dealer, see the optional Tilt Wall Mounting Bracket Installation and Setup Guide.
4 inches
4 inches
4 inches
4 inches
4 inches
<<OOnnllyy 4422PPCC77RR
*
>>
Remove two screws of the backside of the set before
installing the wall mounting bracket.
To Next Page
