LG 32LC3R - Exploded View

- 25 -
EXPLODED VIEW PARTS LIST
No.
PART NO.
DESCRIPTION
ACQ30214604 Cover Assembly, 32LC3R-ZJ LP61A 32" (AUO) CSKD, Front
6304FAU022A
LCD,Module-TFT, T315XW01-V5 XGA 31.5INCH 1366X768 500CD COLOR 72% 16/9 1200:1 SPREAD SPECTRUM
ACQ30217304 Cover Assembly, 32LC3 LP61A 32" 32LC3R-ZJ(CSKD), BACK COVER
AAN30218402 Base Assembly, STAND 32LC3R LP61A CSKD, STAND ASSY
EAB30827201
Speaker,Fullrange, C112K01K1450. FERRITE 15W 8OHM 83.5DB 170HZ 116 X 42 X 38.5 LUG ESTEC AMERICA CORPORATION
EBR32491501 PCB Assembly,Sub, SUB T.T LP61A 32LC3R-ZJ Local Key CKD
EBR30712801 PCB Assembly,Sub, SUB T.T LP61A 32LC3R-ZJ AEUULHX Local Key for DMS
EBR32491301 PCB Assembly,Sub, SUB T.T LP61A 32LC3R-ZJ Preamp CKD
EBR30666501 PCB Assembly,Sub, SUB M.I LP61A 32LC3R AEUULHX Preamp+LED
EBR32491401 PCB Assembly,Sub, SUB T.T LP61A 32LC3R-ZJ Side-AV CKD
EBR30713301 Hand Insert PCB Assembly,Sub, SUB M.I LP61A 32LC3R . 32LC3R Side-AV M.I
AGU30353102 Plate Assembly, ASSY 32LC3, C/SKD
6709900016C
SMPS,AC/DC, LGLP2637HEP 90.0VTO264.0V 215W 47TO63HZ UL/CSA/SEMKO YY / AT / H&E
or 6709900016A Power Supply Assembly, FREE H3/E2 LCD MODEL LCD LG ELECTRONICS LB LC
EBU32591901 Main Total Assembly, 32LC3R-ZJ BRAND LP61A
33139L3011A Main Total Assembly, 32LC2R(AUO) BRAND LP61A
49509K0157R Plate, PRESS H-GI 0.8 SHIELD SPC 32lc3r
35509K0330A Cover, 32LC3 BACK BOTTOM COVER
4810900106A Bracket, COVER 32LC3 LP62A ABS, HF-380 CABLE MANAGEMENT
