LG 32LC56 - Input Signal Modes

- 7 -
3. Optical Feature(LCD Module-LPL)
4. Component Video Input (Y, P
B, PR
)
No
Specification
Proposed
Resolution H-freq(kHz) V-freq(Hz)
1. 720x480 15.73 60.00 SDTV, DVD 480i
2. 720x480 15.63 59.94 SDTV, DVD 480i
3. 720x480 31.47 59.94 480p
4. 720x576 15.625 50.00 SDTV, DVD 625 Line
5. 720x576 31.25 50.00 HDTV 576p
6. 1280x720 45.00 50.00 HDTV 720p
7. 1280x720 44.96 59.94 HDTV 720p
8. 1920x1080 31.25 50.00 HDTV 1080i
9. 1920x1080 33.75 60.00 HDTV 1080i
10. 1920x1080 33.72 59.94 HDTV 1080i
No Item Specification Min. Typ. Max. Remark
1 Viewing Angle [CR>10] R/L, U/D 178, 178
2 Luminance Luminance(cd/m
2
) 320 400 32”
Variation 1.3 MAX/MIN
3 Contrast Ratio CR(32") 600 800 All White/All Black
CR
D (With)(32") 1200 1600 All White/All Black
4 CIE Color Coordinates White Wx Typ 0.285 Typ LPL(26”)
Wy -0.03 0.293 +0.03
Red Xr 0.640
Yr 0.343
Green Xg 0.280
Yg 0.605
Blue Xb 0.145
Yb 0.065
6. RGB PC INPUT Mode Table
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
1. 720X400 31.468 70.08 28.321
2. 640X480 31.469 59.94 25.17 VESA
37.684 75.00 31.50
3. 800X600 37.879 60.31 40.00 VESA
46.875 75.00 49.50
4. 832X624 49.725 74.55 57.283
5. 1024X768 48.363 60.00 65.00 VESA(XGA)
56.470 70.00 75.00
60.123 75.029 78.75
6. 1280X768 47.776 59.870 79.50 VESA(WXGA)
7. 1360X768 47.720 59.799 84.75 VESA(WXGA)
8. 1366X768 47.720 59.799 84.75 Supported
9. 1920X1080 67.50 60.00 148.50
