- 8 -
7. HDMI DTV Mode Table
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Remark Proposed
1. 640X480 31.50 59.94 25.175 SDTV 480p 60Hz
2. 640X480 31.50 60 25.20 SDTV 480p 60Hz
3. 720X480 31.47 59.94 27.00 SDTV 480p 60Hz
4. 720X480 31.47 60 27.027 SDTV 480p 60Hz
5. 720X576 31.25 50.00 27.000 SDTV 576p 50Hz
6. 1280X720 45.00 50.00 74.176 HDTV 720p 50Hz HDCP
7. 1280X720 44.96 59.94 74.176 HDTV 720p 60Hz HDCP
8. 1280X720 44.96 60 74.250 HDTV 720p 60Hz HDCP
9. 1920X1080 28.13 50.00 74.250 HDTV 1080i 50Hz HDCP
10. 1920X1080 33.72 59.94 74.176 HDTV 1080i 60Hz HDCP
11. 1920X1080 33.75 60 74.250 HDTV 1080i 60Hz HDCP
12. 1920X1080 27 24 74.250 HDTV 1080P 24Hz HDCP
13. 1920X1080 56.25 50.00 148.500 HDTV 1080P 50Hz HDCP
14. 1920X1080 67.43 59.94 148.352 HDTV 1080P 60Hz HDCP
15. 1920X1080 67.50 60 148.500 HDTV 1080P 60Hz HDCP
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
1. 720X400 31.468 70.08 28.321
2. 640X480 31.469 59.94 25.17 VESA
37.684 75.00 31.50
3. 800X600 37.879 60.31 40.00 VESA
46.875 75.00 49.50
4. 832X624 49.725 74.55 57.283
5. 1024X768 48.363 60.00 65.00 VESA(XGA)
56.470 70.00 75.00
60.123 75.029 78.75
6. 1280X768 47.776 59.870 79.50 VESA(WXGA)
7. 1360X768 47.720 59.799 84.75 VESA(WXGA)
8. 1366X768 47.720 59.799 84.75 Supported
9. 1920X1080 67.50 60.00 148.50
8. HDMI INPUT Mode Table
