LG 32LD320-ZA - AV2 No Video Problem Troubleshooting; AV2 No Video Flowchart

Check Signal format
Is it supported?
Check the SCART Cable
YES
MAIN B’D JK1101 Check Replace MAIN B’D JK1101
YES
NO
Check MAIN B’D R1133
Video Signal ?
NO
YES
Check MAIN B’D C211
Video Signal ?
Replace MAIN B’D C211
NO
Replace MAIN B’D IC 100
YES
Making
Revision
2009. 2 . 1
LCD TV
Symptom
AV2 No Video Problem
26~42LH2000
32~47LH3000/LH4000
9/34
