PREPARATION
25
1
4
Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
2
Assemble the
SSTTAANNDD BBOODDYY
to the
SSTTAANNDD
BBAASSEE
with the included screws.
Fix the 4 bolts securely using the holes in the
back of the TV.
For 32/42LF20FR
SSTTAANNDD BBOODDYY
CCOOVVEERR BBAASSEE
3
Assemble the TV as shown.
After removing the stand, install the included
pprrootteeccttiioonn ccoovveerr
over the hole for the
stand.
Press the
PPRROOTTEECCTTIIOONN CCOOVVEERR
into the TV
until you hear it click.
PROTECTION COVER
DETACHMENT
Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
1
Loose the bolts from the TV.
2
Detach the stand from the TV.
3
INSTALLATION
